Formliner Mecklenburg
Functional
The functional formliner creates a very smooth, nearly unprocessed concrete surface which is reminiscent of a slate plate. The concrete surface achieves a rank of resistance (to skidding) of R 13.
Technical information
Dimensions
| Series | Uses | Dimensions (mm) | Ordernumber |
|---|---|---|---|
| C | 100 | 5900 1995 | C2201 |
100
100-timer formliners are supplied in an individual dimension within the maximum indicated sizes.
Rank of resistance to skidding of the concrete surface R 13
Section Drawing
The drawing illustrates the cross-section of our formliner.
Profile Continuity
No seamless profile continuity.
Important note: To guarantee homogeneity of the concrete surface, it is not recommended to mix the series.
Material
-
MaterialRECKLI PUR-Elastomer
-
Temperature Limitmax. 65 °C
-
Weight≈ 10 kg/m²
-
Dimensional TolerancesSee Formliner Properties page for details
